Petercem Sensors Newsletter - December 2022

发布时间：2022-12-14
分享到：
Petercem Sensors Newsletter - December 2022

Petercem Sensors


                                          Petercem Sensors Newsletter - December 2022


IRIS standard



Introduced in 2006 by UNIFE (European Rail Supply Industry Association), and

today supported by Alstom-Bombardier, Siemens, CAF and certain railway

equipment manufacturers, the IRIS standard allows a strong and recognized

assessment.

PETERCEM Sensors is certified at bronze level. The successful implementation of IRIS allows

us to create a win-win situation between suppliers, Petercem, and customers. The monitoring

imposed by the IRIS standard involves continuous improvement of the means of production

and the quality of our products, and future development.


Current sensors NCS Range:

Digital technology for accurate measurement


KEY FEATURES

  • Galvanicinsulation between circuits

  • Measurementof all waveforms is possible

  • Choice ofoutput type (current or voltage, IPN or IPMAX)

  • Very largecurrent measuring range (up to 40 kA)

  • Low powerconsumption

  • Simplifiedmechanical fixing.

  • Savings inenergy

  • No rise of temperature around the sensor

APPLICATIONS

  • Sensors to measure DC, AC
    or pulsating currents

  • All mobility systems











Case Study



The applications for these products are diverse, as shown by the fact that Chronix, our distributor in Japan, asked us for a current sensor project for the modernization

of the equipment of a dam. The final customer is HITACHI, a major operator of hydroelectric infrastructures, including the Okutataragi dam.

APPLICATION


Our products are used as sensors for measurements in current

bars for the power supply of the motor pumps of the Okutataragi

dam in Japan. They are central to the operation of the dam. The

simple installation in any critical environment was the key to meet

this challenge. Its low energy consumption and reliability allow it

to be at the heart of today's environmental issues. Diagram

showing the possible uses of the product




KEY NUMBERS

One of the most powerful dam in Japan

Power: 1932 MW

Height of the dam: 72 meters

Length: 577 meters

Upper reservoir capacity: 33,387,000 cubic meters


                                                                                               PETERCEM SENSORS NCS-305







                                                                          Contact us for more info
